LED Frame Panel Light GLAM

Cyanlite LED Frame Panel Light Glam series for Lay-On ceilings

Ordinary LED panel lights are the most used luminaires for normal T15/T24 Lay-On ceiling systems, however, in some projects architects want something different, and here it comes!

The Cyanlite™ LED Frame Lights can be perfectly recessed into the T15/T24 Lay-On ceilings easily and fast, no need any modifications for the ceiling or tile, the luminaire will be under the original ceiling tile and perfectly integrated with the whole ceiling system. Opalic and Prismatic diffusers are optional.

• Advantages

-          Perfectly recessed into the T15/T24 Lay-On ceilings easily and fast

-          Needs no additional installation accessories for RECESSED installation, saving material cost

-          Easy and fast installation, no additional job for screws or adjustment, saving installation cost

-          A wide product range for all major standard Lay-on ceiling tile sizes

-          Flexible and customization oriented, bespoke sizes are welcome

-          Professional LED lighting manufacturer, ODM for EU top lighting brands, no risk for partnership

• Features

l   Standard sizes (mm): 300x1200, 600x600, 600x1200, 625x625, 625x1250

l   RAL9016 as standard coating colors, other RAL colors available on request

l   System Efficiency upto 120 lm/W

l   Opalic and Micro Prismatic diffuser available

l   Range of color temperatures 3000K, 3500K, 4000K, 5000K & 6000K

l   5 Years Warranty

l   Various dimming options, including 0-10V, DALI, Switch Dim etc.

l   Emergency options available

• Specifications

- Light Distribution

- UGR22 with Opalic diffuser                                         - UGR19 with Micro Prismatic diffuser

• Installation

• Certifications

• Downloads

Cyanlite GLAM LED Frame Panel Light datasheet/installation manual/photometric data download
